EBA 430E

EBA 430E ELECTRIC GUILLOTINE
High cutting performance, easy and safe to operate up to A3 format.
Cutting length in mm 430.
Cutting height in mm 40.
Insertion depth in mm 390.
Depth of the front table in mm 230.
Minimum cut in mm 35.
Power connection in volts/Hz 230 / 50.
Engine power in kW 0.45.
Dimensions W x D x H in mm 640 x 695 x 355.
Weight in kg 78.
Electromechanical blade drive.
Optical cutting line indicator.
High quality steel blade.
Manual paper clamp.
Crank with calibration ring for fine adjustment of back gauge.
Spindle-driven backgauge for precise positioning.
Lateral layout graduated in cm and inches.
Adjustable blade guides.
Adjustable blade depth.
Safe and fast blade change.
Desktop version; as option: stand or cabinet available at additional cost.
Two-handed safety activation with snooze lock and
control for synchronous operation.
Clear front safety guard, electrically secured.
Transparent safety cover on the rear table.
Automatic blade return from any position.
Disc brake for immediate blade stop.
Main switch, security lock and key.
